3RF-51SDCD

• 600 MB of free hard disk space

• Available PCI 2.1 or higher compliant slot

• Amplified speakers (available separately)

• CD/DVD-ROM drive required for software installation

Sound card components

Item Description Function

1 Optical S/PDIF Out jack Connects to recording devices with optical connectors (for example, digital audio tape

recorders, minidisc recorders, or external hard disk recorders).

2 Line In/Mic In jack Connects to an external microphone for voice input. Also connects to analog devices like

music synthesizers and other line-level sources.

3 Line Out 1 jack Connects to front left and front right inputs on powered analog speakers or a

multichannel home theater receiver for audio output.

4 Line Out 2 jack Connects to rear left and rear right inputs on powered analog speakers or a multichannel

home theater receiver for audio output.

5 Line Out 3 jack Connects to center and subwoofer inputs on powered analog speakers or a multichannel

home theater receiver for audio output.

RF-51SDCD_09-0960 V3 ENG.fm Page 3 Friday, October 30, 2009 7:05 AM
